Silicone Hose

Hydraulic Low Pressure Push-On Hose For Industrial Non Conductive Application



Short Description:
Product:Push Lock Hose
Type Code:MERCURY
Tube:Black, smooth, NBR rubber
Reinforcement: High strength synthetic cord
Cover: Smooth, synthetic rubber, oil, ozone, aging resistant
Inquiry Download
  • Product Detail
  • Product Tags
Applications
>>>

Compressed air hose for low-pressure hydraulic and pneumatic systems, automation, maintenance, air and water, and general industries. Adaptable with push lock fittings for 300psi application.

Technical Description
>>>

Tube: Black, smooth, NBR rubber

Reinforcement:High strength synthetic cord

Cover:Smooth, synthetic rubber, oil, ozone, aging resistant. Black,

red, yellow, blue, and green colors are available

Temperature Range: -40°C (-40℉) to +100°C (+212℉)

Type
>>>

No. Size I.D. O.D. W.P. B.P. MBR Weight Length
(inch) (mm) (mm) (bar) (psi) (bar) (psi) (mm) (kg/m) (m)
MERCURY-0025 1/4" 6.4  12.7  20  300  80  1200  65 0.13 100
MERCURY-0038 3/8" 9.5  15.9  20  300  80  1200  75 0.16 100
MERCURY-0050 1/2" 12.7  19.8  20  300  80  1200  130 0.27 100
MERCURY-0063 5/8" 15.9  23.0  20  300  80  1200  150 0.28 100
MERCURY-0075 3/4" 19.1  26.2  20  300  80  1200  180 0.36 80
MERCURY-0100 1" 25.4 32.5 20  300  80  1200  250 0.55 60
