Multi-Purpose Food Hose

Flexible hose for suction and discharge fatty and non-fatty foods including milk, beer, vegetable oil, edible oil, grease, etc. Taste-free and odorless. Suitable for Food tankers and food plants. Suitable for 96% alcohol delivery. It can also be used as a ventilation line of tankers to transfer liquid foods with a temperature up to 120°C (not recommended for compressor lines)

 Tube: White, smooth NBR rubber, food-grade, oil resistant, 100% phthalates free

Reinforcement: High strength synthetic cord and steel helix wire

Cover: Blue, smooth, NBR rubber, wrapped finish, abrasion, aging, and wear resistant

Temperature Range: -30°C (-22℉) to + 100°C (+212℉)

*Temperature for steam cleaning should no more than 130°C (266℉)  and lasting time no more than 20min



 FDA 21 CFR 177.2600, EC No. 1935/2004, BfR XXI  cat2, D.M. 21/03/73, GB/T4806.11, Phthalates free, BPA free

No.	Size	I.D.	O.D.	W.P.		B.P.		Vacuum	MBR	Weight	Length
	(inch)	(mm)	(mm)	(bar)	(psi)	(bar)	(psi)	(bar)	(mm)	(kg/m)	(m)
CERES-0075	3/4"	19.1	31.0	10	150	40	600	0.9	60	0.70	40
CERES-0100	1"	25.4	37.0	10	150	40	600	0.9	80	0.85	40
CERES-0125	1-1/4"	31.8	44.0	10	150	40	600	0.9	100	1.03	40
CERES-0150	1-1/2"	38.1	50.0	10	150	40	600	0.9	115	1.28	40
CERES-0158	1-37/64"
